TC-5 is specially designed for field personnel who need an efficient and economical tool for fiber tracing, fiber routing and continuity checking in optical network.
FEATURES
• Metal case: rugged and durable
• Low battery indication: to avoid leakage and wrong judgment
• ESD protection design: to protect the LD effectively
• Integrated case: to avoid the case intermediate broken
• Re-changeable ceramic tube: to avoid returning to manufacturer for this small fault
• Long battery life: up to 60 hours@1mW
SPECIFICATIONS
Type | TC-5-1 | TC-5-10 | TC-5-20 | TC-5-30 | TC-5-50 |
Output Power | 1mw | 10mw | 20mw | 30mw | 50mw |
Test Distance | 5km | 10km | 15km | 20km | 30km |
Wavelength | 650nm±10nm (635nm is optional) | ||||
Emitter Type | FP-LD | ||||
Connector | 2.5mm universal adapter (FC-LC converter is optional) | ||||
Working mode | CW or Pulse | ||||
Pulse Frequency | 2~3HZ | ||||
Power Supply | 2pcs AA battery | ||||
Battery Operating Time | 650nm@1mw ≥65hours; 650nm@10mw≥15hours (Test with Panasonic LR6 AA ALKALINE battery) | ||||
Operating temperature | -10 ~ +45 °C | ||||
Storage temperature | -40 ~ +70 °C | ||||
Weight | 120g (excluding batteries) | ||||
Dimension (mm) | Φ:15; L:210 | ||||
PICTURES
