TC-212 One Step Fiber Cleaver
I. MAIN FEATURES
-- Easy-step operation to complete the cleaving and collection of waste fiber shards.
-- Convenient and quick to operate. Either hand-held or on table/worktop surfaces.
-- Very easy fiber setting and placing and no need for blade height adjustment, therefore improving work efficiency and low maintenance cost.
-- Smart design of pressure pads preventing the fiber from damage by the return of the blade carriage.
-- Small, compact size and light weight.
-- Processed with precision CNC machine, giving precision and stability.
II. SPECIFICATIONS
Product Name | Fiber Cleaver |
Applicable Bare Fiber Diameter | 125μm |
Applicable Fiber Core Count | single-core |
Fiber Cutting Length | 5–20+ mm |
Average Cutting Angle | 0.5° |
Blade Life | 48,000 cuts |
Dimensions | 76.5W*89D*47H (mm) |
Weight | About 180g |
Fiber Clamp | 5-in-1 Fiber Clamp |
III. DETAILED PICTURES
